24101-063050 Marine
BEARING, BALL 6305C3
No. 15
Fig 3
24101-063050 — Affiliate Parts Search
As an Amazon Associate I earn from qualifying purchases. Other links (eBay, AliExpress) are also affiliate links. They help pay for the site, at no extra cost to you. More
Fitted to
Engines, drives and generators whose parts catalogue lists this part. Open any for its exploded parts list.
EnginesOEM interchange
Other OEM part numbers for the same part — order from any of these makers or their dealers.
Aftermarket equivalents cross-ref
Third-party equivalents (Jabsco, Sierra, WIX, Mann…) — not OEM; verify before ordering. Usually cheaper than the marine dealer.
| Equivalent P/N | Brand | Description | Source | Confidence | Shop |
|---|---|---|---|---|---|
| 6305 | SKF | deep-groove ball bearing 25x62x17mm - decoded from Yanmar bearing P/N encoding; 6305 identical across SKF/FAG/NSK/NTN/Koyo/Timken | skf.com | likely |
Standard component cross-ref
An industry-standard component — buy from any bearing / seal / o-ring house; just specify the designation.
| Equivalent P/N | Brand | Description | Source | Confidence | Shop |
|---|---|---|---|---|---|
| 6305 | Bearing | Any-house deep-groove 6305 = Yanmar 24101-063054 - depth:bearings | skf.com | likely |
Used in 5 places
Every catalog figure this part is placed in, the model(s) it applies to, and its reference/level/quantity.
| Model(s) | Catalog | Figure | Page | Ref | Lev | Qty | |
|---|---|---|---|---|---|---|---|
| 1GM | 1GM 2GM 3GM 3HM Parts Catalog | Fig 3. GEAR HOUSING | 10 | 27-1 | 1 | 1 | |
 Fig 3 |
3GM30, 3GM30-YEU, 3GM30C-YEU | 3GM30-YEU Parts Catalog | Fig 3. GEAR HOUSING | 10 | 15 | 1 | 1 |
| 3GM30, 3GM30C, 3GM30VE | 3GM30 Parts Catalog | Fig 3. GEAR HOUSING | 11 | 15 | 1 | 1 | |
 Fig 4 |
3GM30, 3GM30F-YEU, 3GM30FC-YEU | 3GM30-YEU Parts Catalog | Fig 4. GEAR HOUSING | 11 | 15 | 1 | 1 |
| 3GM30B, 3GM30F, 3GM30FVE | 3GM30 Parts Catalog | Fig 4. GEAR HOUSING | 12 | 15 | 1 | 1 |
